Modified Whites Classic II

[kd8hf]

Re: Modified White's Classic II

I'll probably send my Mother in Laws machine but I'm going to have some fun with another Classic ID that I plan on picking up.

I've got all the necessary tools to do the job, like O-scopes, signal generators, VOM, etc. plus a degree in Electronics and computers so I can figure it out.

It will be a nice learning experience.



Amazon Forum Fav 👍

Upgraded Night Vision Monocular Digital Infrared Monocular Telescope for 100% Darkness with 8X Zoom - Grab it through Amazon!

[gallileo60]

Re: Modified White's Classic II

Looks to me you have made your detector into a more expensive unit....I have seen several ham radios where the board had the place for a componet, but it was not there...you did a really nice job.



[gallileo60]

Re: Modified White's Classic II

I'll probably send my Mother in Laws machine but I'm going to have some fun with another Classic ID that I plan on picking up.

I've got all the necessary tools to do the job, like O-scopes, signal generators, VOM, etc. plus a degree in Electronics and computers so I can figure it out.

It will be a nice learning experience.

kd8hf,

Are you a ham? Just wondering cuz of the name you use...KD5YQF here......



[LandStar]

Re: Modified White's Classic II

Hi Mike...
just wondering if you could show the final hookup of the wires to the pots...I could probably figure this out myself, but better safe than sorry...


HH,

LandStar



[Mike95inNJ]

Re: Modified White's Classic II

Hi Mike...
just wondering if you could show the final hookup of the wires to the pots...I could probably figure this out myself, but better safe than sorry...


HH,

LandStar
I sent you an email on it.
Take care, Mike



[X-Terra70_TreasureHunter]

Re: Modified White's Classic II

hi Mike i was just wondering if by chance there was
any way you could put indicator marks around the
Threshold pot & GB pot simular too this photo shure
would look nicer & more Professional



[Mike95inNJ]

Re: Modified White's Classic II

hi Mike i was just wondering if by chance there was
any way you could put indicator marks around the
Threshold pot & GB pot simular too this photo shure
would look nicer & more Professional

I sold that unit to some guy in Russia last year. I use Troy's Shadow X5, Shadow X2, and a Minelab Musketeer now. He seemed very happy with it.
Take care, Mike



[silversurfer1111]

ok i just got a whites classic sl . i would like to add a ground balance pot there are 3 wires i need to solder in after taking off the small pot on the bored . and there are 3 prongs on the 50k pot what wire gos were . pic does the orange wire got to the left prong blue to the middl pron and white to the right prong on the pot ?? thanks for the help



[Oosterbeek]

Hey Mike,

I also did the ground bal en treshold mod my self. As I understand from your post you also did " power balancing over asphalt" could you tell me what that meens? And how I can do it. I hope you can help me.

Sorry for the bad English, I am from Holland. Thats why



[SvenS]

Good job,
Not sure how you removed the trim pot.
If you used desoldering braid with out have come off the board very easy.
Thought I would mention this for future reference or to help others who might do the same mod.
The braid wicks the solder off the pad and part lead so the part will come right off leaving a nice clean pad and hole
